Запчасти Komatsu PC1250-8 МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

706-77-01320

MOTOR ASS'Y

|$4

706-77-03140

MOTOR SUB ASS'Y

1

706-77-42022

CASE,BRAKE

2

706-77-72112

HOUSING

3

706-75-42830

PIN,DOWEL

4

706-77-72170

PLUG

5

07002-12434

O-RING

6

706-77-72130

VALVE

7

706-77-72140

SPRING

8

706-77-72150

PLUG

9

07002-14234

O-RING

10

07000-15250

O-RING

11

01010-61860

BOLT

12

01643-31845

WASHER

13

706-77-42862

SHAFT,DRIVE

14

706-77-42881

BEARING

15

706-77-42890

BEARING

16

706-77-42051

SPRING

17

706-77-42041

SEAT

18

706-77-05010

SPACER KIT

18

SPACER, 2.3MM

18

SPACER, 2.5MM

18

SPACER, 2.7MM

19

04064-06525

RING,SNAP

20

706-77-42920

SEAL,OIL

21

706-77-42060

COVER

22

07000-12115

O-RING

23

04071-00130

RING,SNAP

24

706-77-43191

BLOCK

25

706-77-42851

PLATE,VALVE

26

706-77-42071

BUSHING

27

04020-01024

PIN

28

706-77-42081

SHAFT,CENTER

29

706-77-42130

RING,CENTER

30

706-77-42110

SPRING

|$38

706-77-05020

RETAINER KIT

31

RETAINER

32

SCREW

33

706-77-42160

PISTON SUB ASS'Y

34

706-77-91331

PLATE

35

706-77-91341

PLATE

36

706-77-91350

DISC

37

706-77-91490

PISTON,BRAKE

38

07000-15200

O-RING

39

07001-05200

RING,BACK-UP

40

07000-15220

O-RING

41

07001-05220

RING,BACK-UP

42

706-77-91410

SPRING
