Запчасти Komatsu PC1250-8 ЦИЛИНДР КОВША (/) (ДЛЯ ЭКСКАВАТ.) (ДЛЯ .M И .M РУКОЯТЬ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XR701

CYLINDER GROUP,L.H. (FINAL COATING)

G1

707-01-XR700

CYLINDER GROUP,L.H. (FINAL COATING)

G2

707-01-XR711

CYLINDER GROUP,R.H. (FINAL COATING)

G2

707-01-XR710

CYLINDER GROUP,R.H. (FINAL COATING)

|$9

707-01-0J750

CYLINDER ASS'Y,L.H.

|$10

707-01-0J760

CYLINDER ASS'Y,R.H.

1

721-13-16120

CYLINDER,L.H.

1

721-13-16130

CYLINDER,R.H.

2

707-76-10130

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

707-27-16970

HEAD,CYLINDER

6

707-51-11050

PACKING,ROD (KIT)

7

707-51-11690

RING,BUFFER (KIT)

8

707-52-11630

BUSHING

9

707-75-10512

RING,SNAP

10

707-56-11610

SEAL,DUST (KIT)

11

707-75-11512

RING

12

07000-15150

O-RING (KIT)

13

707-35-91640

RING,BACK-UP (KIT)

14

07000-15150

O-RING (KIT)

15

707-35-91640

RING,BACK-UP (KIT)

16

707-71-35040

COLLAR

17

01010-82090

BOLT

18

707-88-75310

WASHER

19

707-58-11780

ROD,PISTON

20

707-76-10140

BUSHING

21

208-70-12231

SEAL,DUST (KIT)

22

07043-00108

PLUG

23

707-36-16720

PISTON

24

07000-15105

O-RING (KIT)

25

07001-05105

RING,BACK-UP (KIT)

26

707-44-16910

RING

27

707-39-16120

RING,WEAR (KIT)

28

707-44-16150

RING,PISTON (KIT)

29

707-71-71210

PLUNGER

30

01310-01225

SCREW

31

707-71-70850

PLUNGER

32

04260-00635

BALL

33

707-71-91270

CAP

34

707-88-33040

CAP

35

07371-31049

FLANGE,SPLIT

36

07372-21035

BOLT

37

01643-51032

WASHER
