Запчасти Komatsu PC1250-8 КОВШ .M¤ MM (ГОРИЗОНТАЛЬН. ПАЛЕЦ)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21N-939-4312

BUCKET

1

21N-939-4311

BUCKET

2

209-939-4252

SHROUD (WELDED)

2

209-939-4251

SHROUD (WELDED)

3

21N-70-34410

PLATE (WELDED)

4

21N-70-37711

ADAPTER (WELDED)

5

21N-70-41241

ADAPTER (WELDED)

6

21N-939-3G30

PLATE (WELDED)

7

21N-939-3G40

PLATE (WELDED)

8

21N-939-4320

PLATE (WELDED)

9

21N-939-4331

PLATE L.H. (WELDED)

10

21N-939-4341

PLATE R.H. (WELDED)

11

21N-939-4350

PLATE (WELDED)

12

21N-939-4360

PLATE (WELDED)

13

21N-939-4370

PLATE (WELDED)

14

21N-939-4380

PLATE (WELDED)

15

21N-939-4390

PLATE (WELDED)

16

21N-939-4C50

PLATE (WELDED)

17

21N-939-4C60

PLATE (WELDED)

18

21N-939-4C71

PLATE (WELDED)

19

21N-939-4C81

PLATE (WELDED)

20

21N-939-4C90

PLATE (WELDED)

21

21N-939-4D10

PLATE (WELDED)

22

21N-939-4D20

PLATE (WELDED)

23

21N-939-4D30

PLATE (WELDED)

24

21N-939-4D40

PLATE (WELDED)

25

21N-70-37721

TOOTH

26

21N-70-37731

PIN

27

21N-70-14310

COVER

28

01010-83085

BOLT

29

01643-33080

WASHER

30

21N-70-34180

BUSHING

31

21N-70-14220

BUSHING

32

21N-70-00060

SHIM ASS'Y

32

SHIM, 1.0MM

32

SHIM, 0.5MM
