Запчасти Komatsu PC1250-8 PPC ЛИНИЯ СОЕД-Е (СОЕД-Е¤ ДЕКА) (ДЛЯ УДЛИНН. РУКОЯТИ)(№-) ГИДРАВЛИКА

1

02760-00324

HOSE

2

02760-00326

HOSE

3

20Y-62-22790

BAND, RED

4

20Y-62-22820

BAND, BLUE

5

20Y-62-22850

BAND, GREEN

6

23S-61-24870

CLIP

7

01010-81225

BOLT

8

01643-31232

WASHER

9

02760-00314

HOSE

10

02760-00319

HOSE

11

02760-00315

HOSE

12

20Y-62-22810

BAND, YELLOW

13

20Y-62-22840

BAND, BLACK

14

20Y-62-22860

BAND, BROWN

15

02760-00317

HOSE

16

02760-00318

HOSE

17

20Y-62-22790

BAND, RED

18

20Y-62-22830

BAND, WHITE

19

20Y-62-22850

BAND, GREEN

20

04434-53412

CLIP

21

01010-81225

BOLT

22

01643-31232

WASHER

23

02760-00310

HOSE

24

02760-00318

HOSE

25

02760-00319

HOSE

26

20Y-62-22790

BAND, RED

27

20Y-62-22810

BAND, YELLOW

28

20Y-62-22820

BAND, BLUE

29

20Y-62-22830

BAND, WHITE

30

20Y-62-22850

BAND, GREEN

31

04435-51512

CLIP

32

01010-81225

BOLT

33

01643-31232

WASHER

34

21N-62-36580

BRACKET

35

01010-81225

BOLT

36

01643-31232

WASHER

37

20Y-62-15951

CLIP
