Запчасти Komatsu PC1250-7 ЦИЛИНДР РУКОЯТИ(FR LADER) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ550

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XZ560

CYLINDER GROUP,R.H. (FINAL COATING)

|1

21N-63-03121

CYLINDER ASS'Y

1

21N-63-66340

CYLINDER

2

707-46-11510

BUSHING

3

07043-00108

PLUG

4

707-27-18970

HEAD,CYLINDER

5

707-51-13030

PACKING,ROD (KIT)

6

707-51-13630

RING,BUFFER (KIT)

7

707-52-91070

BUSHING

8

707-56-13520

SEAL,DUST (KIT)

9

07179-14146

RING,SNAP

10

07000-15175

O-RING (KIT)

11

707-35-91840

RING,BACK-UP (KIT)

12

01011-82400

BOLT

13

707-88-75410

WASHER

14

21N-63-66320

ROD,PISTON

15

707-46-11510

BUSHING

16

07043-00108

PLUG

17

707-36-18600

PISTON

18

07000-15120

O-RING (KIT)

19

07001-05120

RING,BACK-UP (KIT)

20

707-44-18920

RING

21

707-39-18830

RING,WEAR (KIT)

22

707-44-18280

RING,PISTON (KIT)

23

707-71-51860

PLUNGER

|23

707-71-50390

PLUNGER

24

04260-01270

BALL

25

707-71-91510

PIN

26

01310-01225

SCREW

27

21N-63-66370

TUBE,L.H.

|27

21N-63-66470

TUBE,R.H.

28

21N-62-13241

TUBE

29

07000-13035

O-RING (KIT)

30

01435-01055

BOLT

31

07000-13048

O-RING (KIT)

32

01010-81450

BOLT

33

01643-31445

WASHER

34

707-88-21090

BAND

35

21N-63-66390

BRACKET

36

01010-81240

BOLT

37

01643-31232

WASHER

38

07282-04311

CLAMP

39

01010-81020

BOLT

40

01643-31032

WASHER

41

07283-23442

CLIP

42

01599-01011

NUT

43

01643-31032

WASHER

44

07000-13038

O-RING

45

07378-11210

HEAD

46

07371-51260

FLANGE

47

01010-81245

BOLT

48

01643-31232

WASHER

49

07000-13048

O-RING

50

07378-11410

HEAD

51

07371-51470

FLANGE

52

01010-81455

BOLT

53

01643-31445

WASHER

K

707-99-69670

SERVICE KIT
