Запчасти Komatsu PC1250-7 ВЫПУСКН. КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

6162-13-5280

PIPE,EX

2

6162-14-5640

CAP

3

01010-81235

BOLT

4

01643-31232

WASHER

5

6240-11-5800

MUFFLER

6

01010-E1285

BOLT

7

6142-22-4640

SPACER

8

01580-11210

NUT

9

01643-31232

WASHER

10

6240-11-5751

FLANGE

|10

6240-11-5750

FLANGE

11

6240-11-5760

GASKET

12

01020-11030

BOLT

13

01643-31032

WASHER

14

6240-11-5741

JOINT

|14

6240-11-5740

JOINT

15

6240-11-5510

TUBE

16

6162-13-5660

CLAMP

17

6152-11-4970

SPACER

18

01435-01035

BOLT

19

01584-01008

NUT

20

6204-81-9560

SPACER

21

01435-01080

BOLT

22

07260-20990

HOSE

|22

07261-20990

HOSE

23

07285-00150

CLIP

24

04434-51612

CLIP

25

01010-81225

BOLT

26

01643-31232

WASHER

26A

6240-11-7380

COVER

26B

01010-E1020

BOLT

26C

01643-31032

WASHER

27

6240-11-8740

TUBE

28

6162-13-5611

GASKET

29

01010-E1030

BOLT

30

01643-31032

WASHER

31

07283-35158

CLIP

32

07283-55161

SEAT

33

01597-01009

NUT

34

01643-31032

WASHER

35

6240-11-8750

HOSE

36

07281-00709

CLAMP

37

08671-50160

HOSE

38

04434-51412

CLIP

39

7861-93-1420

SENSOR

40

08037-12536

GROMMET

41

08024-91920

TAPE

42

08193-21012

CLIP

43

01010-81225

BOLT

44

01643-31232

WASHER

45

07287-02611

HOSE

46

07285-00280

CLIP

47

04434-53212

CLIP

48

01010-81225

BOLT

49

01643-31232

WASHER
