Запчасти Komatsu PC1250-7 ЦИЛИНДР КОВША (FR ЭКСКАВАТ.) (ДЛЯ .7M РУКОЯТЬ)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G

707-01-XU570

CYLINDER GROUP,(FINAL COATING)

G

21N-63-X2370

CYLINDER GROUP

|$4

21N-63-02371

CYLINDER ASS'Y

|$5

21N-63-02370

CYLINDER ASS'Y

1

21N-63-72940

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-28-20330

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

5

707-51-14130

PACKING,ROD (KIT)

6

707-51-14640

RING,BUFFER (KIT)

6

707-51-14630

RING,BUFFER (KIT)

7

707-52-91150

BUSHING

7

707-52-11410

BUSHING

8

198-63-93170

SEAL,DUST (KIT)

9

07179-14160

RING

10

07000-15195

O-RING (KIT)

11

707-35-92050

RING,BACK-UP (KIT)

12

07000-15195

O-RING (KIT)

13

07001-05195

RING,BACK-UP (KIT)

14

707-71-31460

COLLAR

15

707-71-11450

RING

16

01011-82705

BOLT

17

01643-32780

WASHER

18

21N-63-72920

ROD,PISTON

19

707-46-14010

BUSHING

20

21T-72-15860

BUSHING

21

21T-72-15870

SEAL,DUST (KIT)

22

07043-00108

PLUG

23

707-36-20300

PISTON

24

07000-12115

O-RING (KIT)

25

707-35-52860

RING,BACK-UP (KIT)

26

707-44-20910

RING

27

707-39-20820

RING,WEAR (KIT)

28

707-44-20180

RING,PISTON (KIT)

29

707-40-20870

SPACER

30

707-71-51471

PLUNGER

31

01252-61460

BOLT

32

21N-63-72970

TUBE

33

21N-63-72980

TUBE

34

07000-13038

O-RING (KIT)

35

07000-13048

O-RING (KIT)

36

01010-81280

BOLT

37

01643-31232

WASHER

38

01010-81450

BOLT

39

01643-31445

WASHER

40

07000-13048

O-RING

41

07378-11410

HEAD

42

07371-51470

FLANGE

43

01010-81455

BOLT

44

01643-31445

WASHER

45

707-88-96110

BAND

46

21N-63-72960

BRACKET

47

21N-63-72990

BRACKET

48

01010-81240

BOLT

49

01643-51232

WASHER

50

176-61-41330

CLAMP

51

01010-81250

BOLT

52

01643-31232

WASHER

53

07283-34346

CLIP

54

01599-01011

NUT

55

01643-31032

WASHER

K

707-99-77190

SERVICE KIT

K

707-99-77120

SERVICE KIT
