Запчасти Komatsu PC1250-7 ЦИЛИНДР КОВША (/) (ДЛЯ ЭКСКАВАТ.) (ДЛЯ .M РУКОЯТЬ) (МОРОЗОУСТОЙЧИВ. СПЕЦИФ-Я)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XR500

CYLINDER GROUP,L.H. (FINAL COATING)

G2

707-01-XR510

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0J510

CYLINDER ASS'Y,L.H.

|$6

707-01-0J520

CYLINDER ASS'Y,R.H.

1

721-13-16080

CYLINDER,L.H.

1

721-13-16090

CYLINDER,R.H.

2

707-76-10130

BUSHING

3

07145-10100

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

707-27-16600

HEAD,CYLINDER

6

707-51-11730

PACKING,ROD (KIT)

7

707-51-11640

RING,BUFFER (KIT)

8

707-52-90860

BUSHING

9

707-75-11040

RING,SNAP

10

198-63-94170

SEAL,DUST (KIT)

11

707-56-11651

SEAL,DUST (KIT)

12

707-88-05190

COLLAR

13

707-88-36541

RING

14

707-88-05200

PLATE

15

07000-55155

O-RING (KIT)

16

07001-05155

RING,BACK-UP (KIT)

17

07000-55155

O-RING (KIT)

18

07001-05155

RING,BACK-UP (KIT)

19

707-71-31660

COLLAR

20

707-71-31181

COLLAR

21

707-71-11150

RING

22

01011-82010

BOLT

23

01011-82015

BOLT

24

707-88-75310

WASHER

25

707-58-11760

ROD,PISTON

26

707-76-10140

BUSHING

27

208-70-12231

SEAL,DUST (KIT)

28

07043-00108

PLUG

29

707-36-16320

PISTON

30

07000-52090

O-RING (KIT)

31

707-35-52930

RING,BACK-UP (KIT)

32

707-44-16910

RING

33

707-39-16820

RING,WEAR (KIT)

34

707-44-16180

RING,PISTON (KIT)

35

707-40-16870

SPACER

36

707-71-61100

PLUNGER

37

01252-61450

BOLT

38

707-71-70220

PLUNGER

39

04260-00635

BALL

40

01312-01220

SCREW

41

707-11-31980

PLATE
