Запчасти Komatsu PC1250-7 ЦИЛИНДР СТРЕЛЫ(/) (МОРОЗОУСТОЙЧИВ. СПЕЦИФ-Я)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XR450

CYLINDER GROUP,L.H. (FINAL COATING)

G2

707-01-XR460

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0J450

CYLINDER ASS'Y

1

707-13-22470

CYLINDER

2

707-46-14010

BUSHING

3

21T-72-15860

BUSHING

4

21T-72-15870

SEAL,DUST (KIT)

5

07043-00108

PLUG

6

707-28-22711

HEAD,CYLINDER

7

707-51-16730

PACKING,ROD (KIT)

8

707-51-16640

RING,BUFFER (KIT)

9

707-52-91350

BUSHING

10

707-75-16110

RING,SNAP

11

566-63-22241

SEAL,DUST (KIT)

12

707-56-16650

SEAL,DUST (KIT)

13

707-88-05090

COLLAR

14

707-88-05080

RING

15

707-88-05100

PLATE

16

07000-55220

O-RING (KIT)

17

707-35-92300

RING,BACK-UP

18

07000-55220

O-RING (KIT)

19

07001-05220

RING,BACK-UP (KIT)

20

707-71-31820

COLLAR

21

707-71-11750

RING

22

01011-83035

BOLT

23

01011-83040

BOLT

24

01643-33080

WASHER

25

707-58-16140

ROD,PISTON

26

707-46-14010

BUSHING

27

21T-72-15860

BUSHING

28

21T-72-15870

SEAL,DUST (KIT)

29

07043-00108

PLUG

30

707-36-22300

PISTON

31

07000-55135

O-RING (KIT)

32

707-35-91440

RING,BACK-UP (KIT)

33

707-44-22920

RING

34

707-39-22820

RING,WEAR (KIT)

35

707-44-22280

RING,PISTON (KIT)

36

707-40-22870

SPACER

37

707-71-51750

PLUNGER

38

01252-61670

BOLT

39

700-11-31980

PLATE, NAME
