Запчасти Komatsu PC1250-7 ОСНОВН. НАСОС (8/) (N. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2L-00610

PUMP ASS'Y

|$3

708-25-85160

SERVO VALVE ASS'Y,FRONT

|$4

708-25-09581

VALVE ASS'Y,CO + NC

|$5

708-23-00430

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-17460

PLUG

4

708-25-17430

SCREW

5

07000-B2010

O-RING

6

708-25-17131

COVER

7

01580-10806

NUT

8

708-25-17141

SPOOL

9

708-25-17150

SLEEVE

10

708-25-17160

PISTON

11

708-25-17170

COVER

12

07000-B2014

O-RING

13

708-25-17180

SEAT

14

708-25-17690

SPRING

15

708-25-17220

PISTON

16

708-25-17370

SEAT

17

708-25-17250

SPRING

18

708-25-17470

SEAT

19

708-23-17290

COVER

20

07000-B3028

O-RING

21

708-25-17380

PLUG

22

708-25-15340

SCREW

23

07000-B2021

O-RING

24

708-23-17240

COVER

25

708-25-17480

PISTON

26

01252-60630

BOLT

26

706-75-40310

BOLT

27

01602-20619

WASHER

28

01252-60616

BOLT

28

708-25-15320

BOLT

29

01602-20619

WASHER

30

01580-10806

NUT

31

07000-B2012

O-RING

32

07001-02012

RING,BACK-UP

33

708-25-17451

SLEEVE

34

07000-B2012

O-RING

35

01252-60616

BOLT

35

708-25-15320

BOLT

36

01602-20619

WASHER

37

07000-B2021

O-RING

38

07001-02021

RING,BACK-UP
