Запчасти Komatsu PC120LC-6E0 ОСНОВН. КЛАПАН (-КЛАПАН) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC120LC-6E0 - ОСНОВН. КЛАПАН (-КЛАПАН) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
16
16
17
17
17
18
18
18
19
20
20
21
21
21
21A
22
23
23A
24
25
26
27
27
27
27A
28
28
29
29
29
29A
30
30
31
32
32
32
32
32
32

Артикул

Название

Примечание

Количество

|$9

723-56-12104

CONTROL VALVE

|$10

723-56-12103

CONTROL VALVE

|$11

723-56-12102

CONTROL VALVE

|$12

723-56-12101

CONTROL VALVE

|$13

723-56-12100

CONTROL VALVE

|$14

723-56-11103

CONTROL VALVE

|$15

723-56-11102

CONTROL VALVE

|$16

723-56-11101

CONTROL VALVE

|$17

723-56-11100

CONTROL VALVE

|$19

BODY GROUP

|$20

BODY GROUP

|$21

BODY GROUP

|$22

BODY GROUP

|$23

BODY GROUP

|$24

BODY GROUP

|$25

BODY GROUP

|$26

BODY GROUP

1

VALVE

1

VALVE

2

VALVE

2

VALVE

2

VALVE

3

VALVE

3

VALVE

4

VALVE

4

VALVE

4

VALVE

5

VALVE

6

PISTON

7

723-56-41810

PLUG

8

723-11-18190

PLUG

9

07002-11023

O-RING

10

723-56-41721

SPRING

11

01643-30623

WASHER

12

01252-60610

BOLT

13

723-56-41821

PLUG

14

723-56-41830

PLUG

15

07002-12034

O-RING

16

723-56-41710

SPRING

17

723-56-41840

PLUG

17

723-56-41840

PLUG

18

07000-13024

O-RING

19

723-26-15230

PLUG

20

07002-12434

O-RING

21

VALVE

21

VALVE

21

VALVE

21A

VALVE

22

VALVE

23

VALVE SUB ASS'Y

23

VALVE SUB ASS'Y

23A

VALVE SUB ASS'Y

24

PISTON

24

PISTON

25

PISTON

25

PISTON

26

PISTON

27

723-56-41730

SPRING

27

723-56-41730

SPRING

27

723-56-41730

SPRING

27A

723-56-41760

SPRING

28

723-56-41740

SPRING

28

723-56-41740

SPRING

29

723-26-15230

PLUG

29

723-26-15230

PLUG

29

723-26-15230

PLUG

29A

723-56-41880

PLUG

30

723-56-41850

PLUG

30

723-56-41850

PLUG

31

723-56-41920

RETAINER

32

07002-12434

O-RING

Выбрано товаров: 71
