Запчасти Komatsu PC120LC-6E0 ОСНОВН. КЛАПАН (-КЛАПАН) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$5

723-56-12104

CONTROL VALVE

|$6

723-56-12103

CONTROL VALVE

|$7

723-56-12102

CONTROL VALVE

|$8

723-56-12101

CONTROL VALVE

|$9

723-56-12100

CONTROL VALVE

|$11

BODY GROUP

|$12

BODY GROUP

|$13

BODY GROUP

|$14

BODY GROUP

|$15

BODY GROUP

1

SPOOL

1

SPOOL

2

SPOOL

2

SPOOL

3

SPOOL

4

SPOOL

4

SPOOL

5

SPOOL

5

SPOOL

6

VALVE

7

VALVE

8

SPRING

8

SPRING

9

PLUG

9

PLUG

10

PLUG

11

PLUG

12

07002-11223

O-RING

12

07002-11223

O-RING

13

SEAL

14

723-56-31211

RETAINER

15

723-56-31221

RETAINER

16

723-36-14120

SPRING

17

723-36-14110

SPRING

18

723-36-14130

SPRING

19

723-36-14140

SPRING

20

723-56-31410

SPRING

21

PISTON

22

PISTON

23

PISTON

24

SEAL

25

723-36-15450

PLUG

26

07002-12434

O-RING

27

723-56-31520

CASE

28

723-56-31530

CASE

29

723-56-31510

CASE

30

723-56-31540

CASE

31

723-56-31550

CASE

32

723-56-31560

CASE

33

702-21-55450

O-RING

34

07000-11006

O-RING

35

01252-60630

BOLT
