Запчасти Komatsu PC120LC-6 ХОД MTOR (МОТОР В СБОРЕ) (GM8VL ТИП)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

22B-60-11330

TRAVEL MOTOR ASS'Y

|$3

TZ276B200001JD

MOTOR

|$4

TZ276B210000-D

FLANGE ASS'Y

|$5

TZ276B210100-D

FLANGE KIT

1

FLANGE

2

SPOOL

3

TZGM1-8

PLUG

4

TZGDL1-16-S

PLUG

5

TZ263B2079-01

FILTER

6

TZ121F2070-00

ORIFICE

7

TZ850A0006-00

PLATE, NAME

8

TZ860A2051-00

PLUG

9

TZ869A2052-00

RETAINER

10

TZ860A2053-02

PLUG

11

TZ860A2054-01

VALVE

12

TZ860A2056-00

SPRING

13

TZ860A2055-01

SPRING

14

TZJB2401-P26-9

O-RING (K1)

15

07000-12016

O-RING (K1)

16

07000-12011

O-RING (K1)

17

TZ200B2073-00

VALVE

18

TZ300B2039-00

STOPPER

19

TZ300B2042-00

RING

20

TZ300B2043-01

SPRING

21

04260-00952

BALL

22

TZ512B2021-00

PLUG

23

07000-12010

O-RING (K1)

24

04260-00793

BALL

25

TZ269B2002-00

SHAFT

26

TZ263B200301-J

PLATE

27

TZ263B2004-04

BLOCK

|$33

TZ263B2105-00

PISTON KIT

|$34

PISTON ASS'Y

28

PISTON

29

SHOE

30

TZ277B2007-00

PLATE

31

TZ263B2008-00

BOWL

32

TZ263B2009-01

PLATE

33

TZ880A2010-00

WASHER

34

TZ263B2011-03

WASHER

35

TZ266B2012-00

PISTON

36

TZ800A2013-00

SPRING

37

TZ263B2093-01

SPRING

38

TZ800A2015-00

PLATE

39

TZ800A2016-00

PLATE

40

TZ263B2074-00

PLATE

41

TZ100A2021-00

PLUG

42

TZ15Z-25-42-10

SEAL (K1)

43

TZ266B2035-00

O-RING (K1)

44

07000-12018

O-RING (K1)

45

TZ266B2039-00

O-RING (K1)

46

TZJB1354-4-10

PIN

47

TZJB1354-10-25

PIN

48

01252-31030

BOLT

49

TZTH-R-42

RING, SNAP

50

TZ263B2048-00

BEARING

51

TZ263B2049-00

BEARING

52

TZ263B2098-00

PIN

|$60

TZ263B2070-00

PISTON

53

PISTON

54

SHOE

55

TZ263B2076-02

PIVOT

56

TZ263B2014-00

COLLAR

57

01252-30865

BOLT

58

TZ263B2077-01

PIN

59

07002-12034

O-RING (K1)

60

TZSW-M8

WASHER

61

TZ263B2090-00

SPRING
