Запчасти Komatsu PC120-6Z ОСНОВН. НАСОС (/)(№77-8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-1L-00043

PUMP ASS'Y

|1

708-1L-00042

PUMP ASS'Y

|1

708-1L-03603

SERVO VALVE ASS'Y

|1

708-1L-03602

SERVO VALVE ASS'Y

|1

708-2L-03811

BODY ASS'Y

1

BODY

2

PLUG

3

EXPANDER

4

708-2L-25480

FILTER

5

708-2L-25490

O-RING

6

708-2L-25631

SPACER

7

708-2L-25760

ORIFICE

8

07000-02110

O-RING

9

708-8E-16150

PLUG

10

07002-11023

O-RING

11

708-2L-25440

PLATE

12

708-2L-25211

SOLENOID ASS'Y

13

07000-02016

O-RING

14

01252-60612

BOLT

15

708-2L-25223

SLEEVE

16

708-2L-25232

SPOOL

17

708-2L-25291

SEAT

18

708-2L-25460

SPRING

19

708-2L-25261

SPRING

20

708-2L-25281

PISTON

21

07040-11007

PLUG

22

07002-01023

O-RING

23

708-2L-25373

LEVER

24

708-2L-25311

PIN

25

708-2L-25330

BEARING

26

708-2L-25321

WASHER

27

01580-00605

NUT

28

708-2L-25340

PLUG

29

01583-11811

NUT

30

07002-01823

O-RING

31

708-2L-25382

PLUG

32

07000-02010

O-RING

33

04065-01610

RING

34

708-2L-25513

SPOOL

35

708-2L-25521

SLEEVE

36

708-2L-25531

PLUG

37

07002-12034

O-RING

38

708-2L-25542

SEAT

39

708-2L-25551

SPRING

40

708-2L-25621

PLUG

41

708-2L-25611

PISTON

42

708-2L-25640

SEAT

43

07001-02012

RING,BACK-UP

44

07000-12012

O-RING

45

01583-12012

NUT
