Запчасти Komatsu PC120-6Z ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№77-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC120-6Z - ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№77-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
14
15
15
16
16
17
17
17
17
17
17
17
17
18
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
32
32
33
34
35
36
37
38
38
39
40
40
40
40

Артикул

Название

Примечание

Количество

|$3

723-37-11105

CONTROL VALVE

|$4

723-37-11104

CONTROL VALVE

|$5

723-37-11102

CONTROL VALVE

1

723-36-15151

PLUG

2

07000-11004

O-RING

3

07001-01004

RING

4

07002-11023

O-RING

5

07040-12412

PLUG

6

07002-02434

O-RING

7

708-8E-16160

PLUG

8

07002-11023

O-RING

9

723-36-15210

SLEEVE

10

723-36-15230

PISTON

11

723-36-15220

PISTON

12

723-36-15340

SPRING

13

723-36-15240

SPRING

14

723-36-15250

CASE

15

07000-03042

O-RING

16

01252-30820

BOLT

17

723-36-41110

VALVE

18

723-36-41121

VALVE

19

723-30-51210

PLUG

20

07002-02434

O-RING

21

723-30-51180

O-RING

22

723-30-51190

RING

23

723-30-66400

VALVE ASS'Y

24

723-30-66300

VALVE ASS'Y

25

723-30-60100

VALVE ASS'Y

26

723-30-66100

VALVE ASS'Y

27

723-30-66200

VALVE ASS'Y

28

723-36-40100

VALVE ASS'Y

29

723-36-41100

VALVE ASS'Y

30

723-36-41200

VALVE ASS'Y

31

723-36-42401

VALVE ASS'Y

31

723-36-42400

VALVE ASS'Y

31

723-36-42100

VALVE ASS'Y

32

723-36-40301

VALVE ASS'Y

33

723-36-41400

VALVE ASS'Y

33

723-36-40400

VALVE ASS'Y

33

723-36-40100

VALVE ASS'Y

34

723-36-43100

VALVE ASS'Y

34

723-36-40100

VALVE ASS'Y

35

723-36-42100

VALVE ASS'Y

36

723-30-56100

VALVE ASS'Y

37

723-30-90201

VALVE ASS'Y,RELIEF

38

709-70-74302

VALVE ASS'Y,SUCTION AND SAFETY

39

709-70-74402

VALVE ASS'Y,SUCTION AND SAFETY

40

723-40-85100

VALVE ASS'Y,SUCTION

40

709-20-81201

VALVE ASS'Y,SUCTION

Выбрано товаров: 49
