Запчасти Komatsu PC120-6Z-A1 КЛАПАН PPC(ДЛЯ ХОДА)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-16-01590

PILOT VALVE

1

BODY,VALVE

2

VALVE

3

702-16-51140

SHIM¤ 0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-51270

SEAL

9

07000-12020

O-RING

10

702-16-54170

COLLAR

11

702-16-57520

CASE

12

LEVER

13

SHAFT

14

PLATE

15

01010-80855

BOLT

16

01643-30823

WASHER

17

01010-80816

BOLT

18

702-16-54331

WASHER¤ 1.60MM

|18

702-16-54341

WASHER¤ 1.30MM

|18

702-16-54351

WASHER¤ 1.00MM

19

04025-00432

PIN,SPRING

20

702-16-54430

BUSHING

21

702-16-54280

SEAL,DUST

22

PLUG

23

PLUG

24

07040-11209

PLUG

25

07002-11223

O-RING

26

702-16-55940

PLUG

27

700-84-11730

BALL

28

702-16-55950

SEAT
