Запчасти Komatsu PC120-6Z-A1 ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№77-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
723-37-11105
CONTROL VALVE
|1
723-37-11104
CONTROL VALVE
|1
723-37-11102
CONTROL VALVE
|1
723-30-66200
VALVE ASS'Y
1
PLUG
2
SEAT
3
BALL
4
07002-12434
O-RING
5
07000-12012
O-RING
6
07001-02012
RING
7
07000-12010
O-RING
8
07001-02010
RING
|9
723-36-40100
VALVE ASS'Y
9
PISTON SUB ASS'Y
10
PISTON
11
PLUG
12
SEAL
13
BALL
14
SLEEVE
15
723-36-41920
SPRING
16
700-80-61260
O-RING
17
700-80-61430
RING
18
07002-13034
O-RING
|19
709-70-74600
VALVE ASS'Y,SUCTION AND SAFETY
19
709-70-71112
SLEEVE
20
SLEEVE
21
POPPET
22
PISTON
23
PLUG
24
POPPET
25
SCREW
26
709-70-71210
SPRING
27
709-70-71220
SPRING
28
SPRING
29
SEAL
30
SEAL
31
709-25-11390
O-RING
32
07002-02434
O-RING
33
O-RING
34
NUT
|35
723-36-48100
VALVE ASS'Y
35
SLEEVE
36
VALVE
37
SEAT
38
POPPET
39
PLUG
40
SCREW
41
NUT
42
NUT
43
SPRING
44
SPRING
45
PLATE
46
CAP
47
SEAL
48
SEAL
49
O-RING
50
RING
51
O-RING
52
O-RING
53
RING
54
O-RING
55
RING
Выбрано товаров: 62
