Запчасти Komatsu PC120-6Z-A1 ХОД MTOR (МОТОР В СБОРЕ) (GM8L ТИП)(№77-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

203-60-63310

TRAVEL MOTOR ASS'Y

|1

TZ250A200000EP

MOTOR,HYDRAULIC

|1

TZ250A2100-00

FLANGE ASS'Y

|1

TZ250A2101-00

FLANGE KIT,REAR

1

FLANGE

2

SPOOL

3

TZGM1-8

PLUG

4

TZGDL1-16-S

PLUG

5

TZ263B2079-01

FILTER

|5

TZ263B2079-00

ORIFICE

6

TZ850A0006-00

PLATE¤ NAME

7

TZ869A2052-00

RETAINER

8

TZ860A2056-00

SPRING

9

TZ860A2051-00

PLUG

10

TZJB2401-P26-9

O-RING (K1)

11

TZ860A2054-01

VALVE

12

TZ860A2055-01

SPRING

13

TZ860A2053-02

PLUG

14

07000-12016

O-RING (K1)

15

TZ600F2073-00

VALVE ASS'Y

16

TZ300B2039-00

STOPPER

17

TZ300B2043-01

SPRING

18

TZ300B2042-00

RING

19

TZ512B2021-00

PLUG

20

07000-12011

O-RING (K1)

21

04260-00952

BALL

22

TZ263B2002-01

SHAFT

23

TZ263B2048-00

BEARING,BALL

24

TZ15Z-22-42-10

SEAL,OIL (K1)

25

TZ263B2014-00

COLLAR

26

TZ263B2004-04

BLOCK,CYLINDER

27

TZ263B2007-01

PLATE,RETAINER

28

TZ263B2105-00

PISTON KIT (9 PIS)

|28

PISTON ASS'Y

|28

PISTON

|28

SHOE

29

TZ263B200301-E

PLATE,SWASH

30

TZ263B2008-00

BOWL,THRUST

31

TZ263B2076-02

PIVOT

32

TZ263B2077-01

PIN

33

TZ263B2011-03

WASHER

34

TZ263B2098-00

PIN

35

TZ263B2093-01

SPRING

36

TZ880A2010-00

WASHER

37

TZTH-R-42

RING,SNAP

38

TZ263B2009-01

PLATE,TIMING

39

TZ263B2049-00

BEARING,BALL

40

TZJB1354-10-25

PIN

41

TZ263B2074-00

PLATE

42

TZ800A2015-00

PLATE

43

TZ800A2016-00

PLATE

44

TZ266B2012-00

PISTON

45

TZ800A2013-00

SPRING

46

TZ266B2035-00

O-RING

47

TZ266B2039-00

O-RING

48

TZ100A2021-00

PLUG

49

07002-02034

O-RING

50

01252-31030

BOLT

51

TZJB1354-4-10

PIN

52

07000-12018

O-RING
