Запчасти Komatsu PC120-6J ОСНОВН. КЛАПАН (-АКТУАТОР) (9/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-39-12104

CONTROL VALVE

|1

723-39-12103

CONTROL VALVE

|1

723-39-12101

CONTROL VALVE

|1

723-39-12100

CONTROL VALVE

1

07000-12014

O-RING

2

07000-13028

O-RING

3

07000-03035

O-RING

4

BODY

5

SPOOL

|5

SPOOL

6

723-36-15130

PLUG

7

07002-10823

O-RING

8

708-7T-16460

BALL

9

723-36-15120

RETAINER

10

723-36-14110

SPRING

11

723-36-15110

CASE

12

723-36-15170

O-RING

13

01252-30622

BOLT

14

01641-20608

WASHER

15

723-36-41110

VALVE

|15

723-36-41110

VALVE

16

SPOOL

|16

SPOOL

17

723-36-12130

SPOOL

18

723-30-66200

VALVE ASS'Y

19

723-36-40100

VALVE ASS'Y

|19

723-36-40100

VALVE ASS'Y

20

723-36-42101

VALVE ASS'Y

|20

723-36-42100

VALVE ASS'Y

21

723-36-41100

VALVE ASS'Y

21A

723-36-48100

VALVE ASS'Y

22

709-70-74600

VALVE ASS'Y,SUCTION AND SAFETY

23

709-70-74302

VALVE ASS'Y,SUCTION AND SAFETY

|23

709-70-74402

VALVE ASS'Y,SUCTION AND SAFETY

24

723-40-85100

VALVE ASS'Y,SUCTION

|24

709-21-81201

VALVE ASS'Y,SUCTION
