Запчасти Komatsu PC120-6H ОСНОВН. КЛАПАН (-КЛАПАН) (9/)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
723-56-12103
CONTROL VALVE
|1
723-56-12102
CONTROL VALVE
|1
723-56-12101
CONTROL VALVE
|1
723-56-12100
CONTROL VALVE
|1
723-56-11103
CONTROL VALVE
|1
723-56-11102
CONTROL VALVE
|1
723-56-11101
CONTROL VALVE
|1
723-56-11100
CONTROL VALVE
|$$9
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1661-01A0 TO Y1661-11A0.
|1
723-50-51400
VALVE ASS'Y
|1
723-50-51300
VALVE ASS'Y
|1
723-50-51100
VALVE ASS'Y
1
BLOCK
2
SPOOL
|2
SPOOL
|2
SPOOL
3
723-50-51230
SPRING
|3
723-50-51130
SPRING
4
723-50-51140
PLUG
5
07002-11623
O-RING
6
723-50-51150
FLANGE
7
07000-12011
O-RING
8
07000-11007
O-RING
9
01252-60620
BOLT
10
BALL
11
723-50-51160
PLUG
12
07000-11003
O-RING
13
07002-10823
O-RING
14
SCREW
15
07000-11008
O-RING
|16
723-50-52200
VALVE ASS'Y
|16
723-50-52100
VALVE ASS'Y
16
BLOCK
17
SPOOL
18
723-50-52130
RETAINER
19
723-50-52150
SPRING
|19
723-50-52140
SPRING
20
723-56-31630
PLUG
21
07002-11623
O-RING
22
BALL
23
723-50-51160
PLUG
24
07000-11003
O-RING
25
07002-10823
O-RING
26
723-56-41620
ORIFICE
27
723-11-18190
PLUG
28
07002-11023
O-RING
29
SCREW
30
07000-11008
O-RING
31
07000-11007
O-RING
|32
723-50-54100
VALVE ASS'Y
32
723-50-54110
BLOCK
33
723-56-31610
VALVE
34
723-56-31620
SPRING
35
723-56-31630
PLUG
36
07002-11623
O-RING
37
723-11-18190
PLUG
38
07002-11023
O-RING
39
07000-11009
O-RING
40
708-2L-25490
O-RING
Выбрано товаров: 59
