Запчасти Komatsu PC120-6H ХОД MTOR (МОТОР В СБОРЕ) (GM8VL ТИП)(№-77) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC120-6H - ХОД MTOR (МОТОР В СБОРЕ) (GM8VL ТИП)(№-77) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
3
4
5
5A
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43

Артикул

Название

Примечание

Количество

|1

203-60-63102

TRAVEL MOTOR ASS'Y

|1

203-60-63101

TRAVEL MOTOR ASS'Y

|$$3

(203-60-63102(2))

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A0¤ 02A0 AND 03A0.

|1

TZ218B200000QF

HYDRAULIC MOTOR A.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A0 AND Y1651-02A0.

1

TZ203B210101-F

FLANGE KIT,REAR

2

TZMB700-070

PLUG

3

TZGM1-4

PLUG

4

TZGM1-8

PLUG

5

TZMB700-050

PLUG

5A

TZ850A0006-00

PLATE¤ NAME

6

04260-00793

BALL

7

TZ200B2105-00

PISTON KIT (9 PIECES)

8

TZ200B2004-00

BLOCK,CYLINDER

9

TZ200B200301-Q

PLATE,SWASH

10

TZ201B2032-01

PLATE,THRUST

11

TZ200B2007-01

PLATE,RETAINER

12

TZ200B2008-00

BOWL,THRUST

13

TZJB150635-328

PIN

14

TZ150A2010-00

WASHER

15

TZ200B2014-00

SPRING

16

TZIRTW-55

RING,SNAP

17

TZ200B2170-01

PISTON

18

TZ200B2074-00

PLATE

19

TZ200A2015-00

DISC

20

TZ100A2016-00

PLATE

21

TZ231F2012-00

PISTON

22

TZ100A2013-00

SPRING

23

07000-15145

O-RING (K1)

24

TZ231F2023-00

RING,BACK-UP (K1)

25

07000-15170

O-RING (K1)

26

TZSUN-2BG170

RING,BACK-UP (K1)

27

TZ200B2002-01

SHAFT

28

TZJB1501-26

BALL

29

06000-06207R

BEARING

30

TZTCN-32-52-11

SEAL,OIL (K1)

31

TZ210A2009-00

PLATE,TIMING

32

TZJB1354-5-12

PIN

33

06000-06204

BEARING

34

TZ200B2019-00

VALVE

35

TZ100A2020-00

SPRING

36

07000-11009

O-RING (K1)

37

TZ100A2018-00

SEAT,VALVE

38

TZ100A2022-00

RING

39

TZ200B2073-00

VALVE

40

TZ300B2043-01

SPRING

41

TZ300B2039-00

STOPPER

42

TZ300B2042-00

RING

43

TZ200B2085-00

SPRING

Выбрано товаров: 50
