Запчасти Komatsu PC120-6H ЦИЛИНДР КОВША (/) (ДЛЯ HYPER GX) (УДЛИНН. СИСТ. СМАЗКИ ТИП)(№7-89) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

203-63-X7740

CYLINDER GROUP,BUCKET

|$$2

====================

|1

203-63-07740

CYLINDER ASS'Y,BUCKET

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1620-41A2A AND Y1620 -42A2A.

1

203-63-94241

CYLINDER

2

203-70-66150

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

707-27-95130

HEAD,CYLINDER

6

707-52-90400

BUSHING

7

707-51-65630

RING,BUFFER (KIT)

8

707-51-65030

PACKING,ROD (KIT)

9

07000-15090

O-RING (KIT)

10

07001-05090

RING,BACK-UP (KIT)

11

707-27-95140

HEAD

12

07177-06515

BUSHING

13

07000-02080

O-RING (KIT)

14

144-63-92170

SEAL,DUST (KIT)

15

07179-12079

RING,SNAP

16

01252-61445

BOLT

17

01011-81410

BOLT

18

705-17-04980

WASHER

19

203-63-94221

ROD,PISTON

20

707-76-65220

BUSHING

21

707-77-65110

SEAL,DUST (KIT)

22

07020-00675

FITTING,GREASE

23

707-36-95410

PISTON

24

707-44-95180

RING,PISTON (KIT)

25

707-39-95120

RING,WEAR (KIT)

26

707-44-95911

RING

27

07165-14547

NUT

28

7861-92-6102

SENSOR

29

07000-03025

O-RING (KIT)

|$$34

====================
