Запчасти Komatsu PC120-6H ОСНОВН. НАСОС (/9)(№-8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-1L-00070

PUMP ASS'Y

|1

708-1L-00032

PUMP ASS'Y

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 TO Y1600-09A0.

|1

708-1L-01070

PUMP SUB ASS'Y

|1

708-1L-01032

PUMP SUB ASS'Y

1

708-1L-24110

PISTON

2

700-90-61281

SEAL

3

708-2L-24122

ROD

4

708-2L-25883

CAM

5

04020-00514

PIN

6

01010-80620

BOLT

7

01643-30623

WASHER

8

708-2L-24161

STOPPER

9

708-2L-24920

O-RING

10

07001-03025

RING,BACK-UP

11

708-2L-24220

BOLT

12

708-2L-24230

WASHER

13

708-2L-24151

SEAT

14

708-2L-05010

SHIM KIT

|14

SHIM¤ 0.1MM

|14

SHIM¤ 0.2MM

|14

SHIM¤ 0.5MM

15

708-2L-24312

SCREW

16

07000-B2018

O-RING

17

07001-02018

RING,BACK-UP

18

01583-12716

NUT

19

708-2L-24340

SEAL,WASHER

20

708-2L-24141

SPRING

21

708-2L-24131

PLUG

22

07000-03030

O-RING

23

07043-01222

PLUG
