Запчасти Komatsu PC120-6H ИНСТРУМЕНТ КОРПУС(№-89) ЧАСТИ КОРПУСА

1

203-54-67601

CASE

|1

203-54-67600

CASE

|$$3

(203-54-67601{14X-54-12590(2))}

2

203-54-67620

COVER

3

203-54-67741

HINGE (WELDED)

|3

203-54-67740

HINGE (WELDED)

4

421-54-11372

LOCK ASS'Y (WELDED)

5

421-54-11381

LOCK

6

203-54-67630

SEAL

7

203-54-67640

SEAL

8

203-54-67650

SEAL

9

203-54-67660

SEAL

10

203-54-67670

SEAL

11

203-54-67760

SEAL

12

203-54-56630

ROD

13

01643-30623

WASHER

14

04050-11612

PIN

15

21W-06-22120

LAMP ASS'Y

16

421-06-23330

BULB¤ 70W

17

08037-12536

GROMMET

18

08037-13550

GROMMET

19

21T-06-11350

TANK ASS'Y

20

01010-80616

BOLT

|20

01010-50616

BOLT

21

01643-30623

WASHER

22

203-06-61132

WIRING HARNESS

23

195-979-8590

VALVE,(SEE FIG.K0350-01A0)

24

01010-81230

BOLT

|24

01010-51230

BOLT

25

124-54-26540

WASHER

26

14X-54-12590

CAP

27

203-54-67770

COVER

28

01010-81230

BOLT

|28

01010-51230

BOLT

29

01643-31232

WASHER
