Запчасти Komatsu PC120-6E0-T2 1-Я СТРЕЛА ЦИЛИНДР (ДЛЯ 2 ЧАСТИS СТРЕЛА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

203-63-X2351

CYLINDER GROUP,L.H.

G2

203-63-X2361

CYLINDER GROUP,R.H.

|1

203-63-02351

CYLINDER ASS'Y,L.H.

|1

203-63-02361

CYLINDER ASS'Y,R.H.

1

203-63-54741

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-27-10610

HEAD,CYLINDER

5

707-52-90400

BUSHING

6

707-51-65630

RING,BUFFER (KIT)

7

707-51-65030

PACKING,ROD (KIT)

8

144-63-92170

SEAL,DUST (KIT)

9

07179-12079

RING,SNAP

10

07000-15095

O-RING (KIT)

11

07001-05095

RING,BACK-UP (KIT)

12

707-71-32311

COLLAR

13

07000-15095

O-RING (KIT)

14

07001-05095

RING,BACK-UP (KIT)

15

01010-81465

BOLT

16

705-17-04980

WASHER

17

203-63-54720

ROD,PISTON

18

707-76-70230

BUSHING

19

07145-00070

SEAL,DUST (KIT)

20

707-71-60681

PLUNGER

21

707-41-10190

WASHER

22

707-36-10210

PISTON

23

707-44-10180

RING,PISTON (KIT)

24

707-39-10110

RING,WEAR (KIT)

25

707-44-10411

RING

26

07165-14547

NUT

27

203-63-54771

TUBE,L.H.

|27

203-63-54871

TUBE,R.H.

28

203-63-54780

TUBE,L.H.

|28

203-63-54880

TUBE,R.H.

29

07000-13025

O-RING (KIT)

30

01010-50850

BOLT

31

01643-50823

WASHER

32

203-63-54791

BRACKET

33

707-88-95010

BAND

34

01010-51035

BOLT

35

01643-51032

WASHER

36

01010-51030

BOLT

37

01643-31032

WASHER

|K

707-99-36290

SERVICE KIT
