Запчасти Komatsu PC120-6 ЦИЛИНДР 2-Й СТРЕЛЫ (ДЛЯ 2 ЧАСТИS СТРЕЛА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

203-63-X2371

BOOM CYLINDER GROUP

|1

203-63-02371

CYLINDER ASS'Y

1

203-63-54941

CYLINDER

2

207-76-70110

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

203-63-54920

ROD,PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12620

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90600

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15115

O-RING (KIT)

13

07001-05115

RING,BACK-UP (KIT)

14

707-51-85630

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12411

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12110

RING,WEAR (KIT)

20

707-44-12911

RING

21

07165-15860

NUT

22

203-63-54970

TUBE

23

203-63-54980

TUBE

24

07372-21060

BOLT

25

07372-21045

BOLT

26

01643-51032

WASHER

27

07000-13030

O-RING (KIT)

28

202-966-6191

BRACKET

29

01010-51035

BOLT

30

01643-51032

WASHER

31

07283-22236

CLIP

32

01599-01011

NUT

33

01643-31032

WASHER

34

07020-00000

FITTING,GREASE

35

07020-00675

FITTING,GREASE

|K

707-99-46230

SERVICE KIT
