Запчасти Komatsu PC120-6 ОСНОВН. КЛАПАН (8-КЛАПАН) (/) (С ОТВАЛ)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
723-58-12505
CONTROL VALVE
|1
723-58-12504
CONTROL VALVE
|1
723-58-12503
CONTROL VALVE
|1
723-58-12502
CONTROL VALVE
|1
723-58-12501
CONTROL VALVE
|1
723-58-12500
CONTROL VALVE
|1
723-58-11503
CONTROL VALVE
|1
723-58-11502
CONTROL VALVE
|1
723-58-11501
CONTROL VALVE
|1
723-58-11500
CONTROL VALVE
|1
723-51-01700
VALVE ASS'Y
|1
723-51-01202
VALVE ASS'Y
|1
723-51-01201
VALVE ASS'Y
|1
723-51-01200
VALVE ASS'Y
|1
723-50-42103
VALVE ASS'Y
|1
723-50-42100
VALVE ASS'Y
1
SLEEVE
|1
SLEEVE
2
07000-13024
O-RING
3
SEAT
|3
SEAT
4
SEAL
|4
SEAL
5
POPPET
6
SPRING
7
PLUG
|7
PLUG
8
O-RING
9
RING
10
SCREW
11
O-RING
12
RING,BACK-UP
13
NUT
|13
NUT
14
PLATE
|14
PLATE
15
NUT
16
CAP
17
723-56-31640
PLUG
18
07002-11623
O-RING
19
07000-11008
O-RING
|20
709-70-74600
VALVE ASS'Y,SUCTION AND SAFETY
20
SLEEVE
21
SLEEVE
22
POPPET
23
PISTON
24
PLUG
25
POPPET
26
SCREW
27
SPRING
28
SPRING
29
SPRING
30
SEAL
31
SEAL
32
709-25-11390
O-RING
33
O-RING
34
O-RING
35
NUT
Выбрано товаров: 58
