Запчасти Komatsu PC120-5K ЦИЛИНДР КОВША(№K-K9) РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|1

203-63-K1810

CYLINDER ASS'Y,BUCKET

1

203-63-K2470

CYLINDER

2

707-76-65210

BUSHING

3

07145-00065

SEAL,DUST

4

203-63-K2370

FITTING,GREASE

5

203-63-K2490

HEAD,CYLINDER

6

707-52-90400

BUSHING

7

707-51-65030

PACKING,ROD

8

203-63-K2560

RING,BACK-UP

9

707-51-65630

RING,BUFFER

10

203-63-K2530

O-RING

11

203-63-K2540

RING,BACK-UP

12

144-63-92170

SEAL,DUST

13

203-63-K2570

RING,SNAP

14

203-63-K2380

BOLT

15

203-63-K2480

ROD,PISTON

16

707-76-65220

BUSHING

17

707-77-65110

SEAL,DUST

18

203-63-K2370

FITTING,GREASE

19

203-63-K2510

PISTON

20

203-63-K2550

O-RING

21

707-44-95180

RING,PISTON

22

707-39-95120

RING,WEAR

23

707-44-95911

RING

24

203-63-K2050

SCREW,SET

25

202-63-74370

TUBE

|25

203-63-K2650

TUBE

26

202-63-74380

TUBE

|26

203-63-K2670

TUBE

27

07000-13025

O-RING

28

01010-50850

BOLT

|28

203-63-K2240

BOLT

29

707-88-96250

BAND

|29

203-63-K2680

BAND

30

707-88-95531

BRACKET

|30

203-63-K2690

BRACKET

31

01010-51035

BOLT

|31

203-63-K2210

BOLT

32

01643-51032

WASHER

|32

203-63-K2220

WASHER

33

707-88-96260

BAND

|33

203-63-K2710

BAND

34

707-88-95540

BRACKET

|34

203-63-K2720

BRACKET

35

07283-22236

CLIP

|35

203-63-K2190

CLIP

36

01599-01011

NUT

|36

203-63-K2790

NUT

37

01643-31032

WASHER

|37

203-63-K2230

WASHER

38

01643-50823

WASHER
