Запчасти Komatsu PC120-5 ГИДРОЛИНИЯ (НАВЕСНОЕ ОБОРУД-Е) (-ACTUATER НАВЕСН. ОБОРУД)(СТРЕЛА) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

202-973-6590

HOSE

2

07097-21013

HOSE

3

07000-13032

O-RING

4

07371-31049

FLANGE,SPLIT

5

07372-21035

BOLT

6

01643-51032

WASHER

7

203-973-5580

TUBE

8

203-973-5861

TUBE

9

203-973-5881

TUBE

10

202-973-6480

HOSE, 2150MM

11

203-973-5560

TUBE

12

203-973-5600

VALVE ASS'Y,(SEE FIG.7113)

12

07040-12012

PLUG

13

07002-12034

O-RING

14

07040-12012

PLUG,(WITHOUT ACCUMULATOR)

14

203-973-5610

UNION,(WITH ACCUMULATOR)

15

07002-12034

O-RING

16

07040-11007

PLUG

17

07002-11023

O-RING

18

203-973-5640

BRACKET

19

01010-51020

BOLT

20

01010-51045

BOLT

21

01643-31032

WASHER

22

203-973-5670

CLAMP

23

01010-51025

BOLT

24

01643-31032

WASHER

25

203-973-5660

CLAMP

26

01010-51025

BOLT

27

01643-31032

WASHER

28

203-973-5650

CLAMP

29

01010-51035

BOLT

30

01643-31032

WASHER

31

202-973-6430

SEAT

32

202-973-6440

SEAT

33

202-973-6460

CUSHION

34

203-62-58810

CUSHION

35

202-973-6470

CUSHION

36

203-70-53381

PLATE

37

01010-51025

BOLT

38

01643-31032

WASHER

39

202-973-6450

PLATE

40

01010-51025

BOLT

41

01643-31032

WASHER

42

2988-01-3630

ACCUMULATOR

43

07002-12034

O-RING

44

08036-03014

CLIP

45

203-62-32440

COVER
