Запчасти Komatsu PC110R-1 СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC110R-1 - СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ
43
42
41
43
47
46
47
A
A
20
28
27
24
23
31
22
25
39
17
32
30
29
30
33
17
21
12
39
38
2
8
10
11
9
14
13
16
37
38
38
35
1
38
13
15
34
18
45
19
44
40
A
A
B
C
D
E
F

Артикул

Название

Примечание

Количество

\0

226-01-11501

ENGINE, ASSY.

1

YM129466-49300

FUSE BOX

2

YM123907-42000

WATER PUMP, ASSY.

8

YM23875-030000

PLUG

9

YM23875-020000

PLUG

10

YM119802-49112

PIPE

11

YM24190-080001

BEARING

12

YM123900-42050

GASKET

13

YM26106-060502

BOLT

14

YM26106-080552

BOLT

15

YM129930-42400

PULLEY

16

YM25133-004700

V-BELT

17

YM121450-42450

PLUG

18

YM123910-44771

SPACER

19

YM26106-060122

BOLT

20

YM26106-100702

BOLT

21

YM123945-49810

THERMOSTAT, ASSY.

22

YM105010-39140

BOLT

23

YM124910-49291

GASKET

24

YM124910-49291

GASKET

25

YM123500-49550

GASKET

27

YM23876-030000

PLUG

28

YM26106-080252

BOLT

29

YM23387-040800

JOINT

30

YM23414-080000

GASKET

31

YM123900-49820

GASKET

32

YM26106-080702

BOLT

33

YM26106-080702

BOLT

34

YM123912-49031

PIPE

35

YM123907-49060

PIPE

37

YM123910-49610

PROTECTION

38

YM23000-025000

CLAMP

39

YM124465-44950

GASKET

40

YM123945-49610

PIPE, ASSY.

41

YM123945-49700

PIPE, ASSY.

42

YM123907-49710

PIPE

43

YM124722-59050

CLAMP

44

YM129486-59320

PIPE

45

YM123907-49620

PIPE, ASSY.

46

YM123907-49720

PIPE

47

YM124722-59050

CLAMP

Выбрано товаров: 41
