Запчасти Komatsu PC110R-1 СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ

\0

226-01-11000

MOTOR, ASSY.

1

YM128270-13620

UNION

2

YM123900-42000

PUMP, ASSY.

10

YM123900-42050

GASKET

11

YM26106-060502

BOLT PLATED

12

YM26106-080552

BOLT

13

YM123900-42450

PULLEY

14

YM123900-42480

V-BELT

15

YM123910-44740

FAN

16

YM123900-44760

SPACER

17

YM26106-100452

SCREW

18

YM123900-49800

THERMOSTAT CASE, ASSY.

19

YM124610-48620

THERMOSTAT

20

YM124610-49290

GASKET

21

YM123550-49530

COVER

22

YM123500-49550

GASKET

24

YM23871-030000

PLUG

25

YM26106-080142

BOLT

26

YM123900-49820

GASKET

27

YM26106-080602

BOLT

28

YM26106-080702

BOLT

29

YM123912-49030

PIPE

30

YM123910-49040

PIPE

31

YM123912-49200

BLOCK, EXHAUST

38

YM123910-49600

PIPE, ASSY.

40

YM123910-49610

PROTECTION

41

YM23000-025000

CLAMP

42

YM26106-080402

BOLT

43

YM121450-42450

PLUG

44

YM121250-44901

WATER TEMPERATURE TRANSMITTER (ALARM)

45

YM124465-44950

GASKET

46

YM124465-44950

GASKET

47

YM121851-11970

UNION
