Запчасти Komatsu PC110R-1 ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC110R-1 - ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ
28
13
28
31
28
28
31
33
28
28
31
59
28
58
57
28
58
32
57
17
44
18
15
43
28
29
10
58
13
59
58
22
41
6
24
45
30
12
22
41
4
26
56
25
23
52
14
22
2
6
13
22
20
53
24
35
1
47
13
9
34
42
7
42
46
3
5
50
55
54
21
48
52
51
49
19
A
B
C
C
C
B

Артикул

Название

Примечание

Количество

\0

226-01-11000

MOTOR, ASSY.

1

YM119000-55600

FILTER

2

YM129470-55610

BODY

3

YM194180-51640

RETAINER

4

YM26106-100252

BOLT

5

YM26106-100142

BOLT

6

YM101304-59020

UNION

7

YM129957-59040

PIPE, ASSY.

9

YM119560-59110

PROTECTION

10

YM119560-59051

PIPE, ASSY.

12

YM119560-59110

PROTECTION

13

YM124766-59050

CLAMP

14

YM121750-59890

CLAMP

15

YM103854-59191

CAP, ASSY.

17

YM124060-59380

PLUG

18

YM22190-060002

SPRING WASHER

19

YM121855-59880

JOINT

20

YM121855-59880

JOINT

21

YM119006-59910

JOINT

22

YM22190-120002

GASKET

23

YM23857-060000

BOLT

24

YM124766-59050

CLAMP

25

YM129957-59050

PIPE, ASSY.

26

YM129957-59120

PROTECTION

28

YM124066-59100

CLAMP

29

YM129495-59300

BOLT

30

YM129980-59530

JOINT

31

YM121250-59550

PIPE

32

YM124732-59562

PIPE

33

YM129150-59580

PLUG

34

YM121855-59880

JOINT

35

YM128300-59910

VALVE

41

YM22190-140002

GASKET

42

YM22190-140002

GASKET

43

YM23414-080000

GASKET

44

YM26106-080102

SCREW

45

YM120324-55750

WATER SEPARATOR

46

YM120324-55760

FILTER

47

YMX0582810173

GASKET

48

YMX0580121073

O-RING

49

YMX0311121522

BOLT

50

YMX0300120414

GASKET

51

YMX0313080110

SCREW

52

YMX0588080273

GASKET

53

YMX2740134001

COVER

54

YMX2540025002

TANK

55

YMX0600160122

SPRING

56

YMX0314080110

PLUG

57

YM121750-59910

JOINT

58

YM22190-140002

GASKET

59

YM23857-080000

JOINT

Выбрано товаров: 51
