Запчасти Komatsu PC110R-1 ТОПЛ. НАСОС ДВИГАТЕЛЬ

Схема запчастей Komatsu PC110R-1 - ТОПЛ. НАСОС ДВИГАТЕЛЬ
19
27
21
22
20
17
97
18
98
6
7
16
92
15
5
9
8
96
61
11
10
60
94
95
99
91
3
93
90
66
67
81
71
4
13
62
14
63
64
65
101
2
100
58
70
72
68
57
69
59
28
1
23
24
26
25
12

Артикул

Название

Примечание

Количество

\0

226-01-11000

MOTOR, ASSY.

1

YM123912-51010

PUMP, ASSY.

1

REGULATOR, ASSY.

2

YMX1313110000

GASKET

3

YMX1310661820

HOUSING

4

YMX0290406020

STUD

5

YMX1340260000

PLUG

6

YMX1310024700

PLUG

7

YMX1310024700

PLUG

8

YMX1310286220

COVER

9

YMX1310111900

GASKET

10

YMX1310171000

SCREW

11

YMX0293406020

GASKET

12

YMX1310341501

PLUG

13

YMX1392060400

NUT

14

YMX0296331010

O-RING

15

YMX1311502920

PLUNGER

16

YMX1311608520

VALVE DELIVERY

17

YMX1311122900

SPRING

18

YMX1311151200

GASKET

19

YMX1311168220

GUARD, DELIVERY VALVE

20

YMX1311173100

STOPPER

21

YMX1311220520

PLATE

22

YMX0296320070

O-RING

23

YMX1312002720

TAPPET

24

YMX1312030500

PIN

25

YMX1312041100

WHEEL

26

YMX1312050600

BUSHING

27

YMX1312060700

GUIDE

28

YMX0293110020

SHIM, 0.300 mm

28

YMX0293110030

SHIM, 0.400 mm

28

YMX0293110040

SHIM, 0.500 mm

28

YMX0293110050

SHIM, 0.600 mm

28

YMX0293110060

SHIM, 0.700 mm

28

YMX0293110070

SHIM, 0.800 mm

28

YMX0293110080

SHIM, 0.900 mm

28

YMX0293110090

SHIM, 1.000 mm

28

YMX0293110110

SHIM, 1.100 mm

28

YMX0293110120

SHIM, 1.200 mm

28

YMX0293110130

SHIM, 1.300 mm

28

YMX0293110140

SHIM, 1.400 mm

28

YMX0293110270

SHIM, 0.550 mm

28

YMX0293110280

SHIM, 0.650 mm

28

YMX0293110290

SHIM, 0.750 mm

28

YMX0293110310

SHIM, 0.850 mm

28

YMX0293110320

SHIM, 0.950 mm

28

YMX0293110330

SHIM, 1.050 mm

28

YMX0293110340

SHIM, 1.150 mm

28

YMX0293110350

SHIM, 1.250 mm

28

YMX0293110490

SHIM, 1.500 mm

28

YMX0293110500

SHIM, 1.600 mm

28

YMX0293110580

SHIM, 0.200 mm

28

YMX0293110590

SHIM, 0.250 mm

28

YMX0293110600

SHIM, 0.350 mm

28

YMX0293110610

SHIM, 0.450 mm

28

YMX0293110620

SHIM, 1.350 mm

28

YMX0293110630

SHIM, 1.450 mm

28

YMX0293110710

SHIM, 1.550 mm

57

YMX1312152100

SPRING

58

YMX1312160400

SEAT

59

YMX1312170600

SEAT

60

YMX1312540600

RACK

61

YMX1312260300

SCREW

62

YMX1312400100

CLAMP

63

YMX1312410500

SLEEVE

64

YMX1312420100

SCREW

65

YMX1313661600

CAMSHAFT

66

YMX0166402030

BEARING

67

YMX0282020020

BEARING

68

YMX0166402030

BEARING

69

YMX0282020020

BEARING

70

YMX1313021000

SPACER

71

YMX1313021000

SPACER

72

YMX0293120220

SHIM

72

YMX0293120230

SHIM

72

YMX0293120240

SHIM

72

YMX0293120250

SHIM

72

YMX0293120260

SHIM

72

YMX0293120270

SHIM

72

YMX0293120290

SHIM

72

YMX0293120300

SHIM

72

YMX1394200400

SHIM, 0.700 mm

81

YMX0293120220

SHIM

81

YMX0293120230

SHIM

81

YMX0293120240

SHIM

81

YMX0293120250

SHIM

81

YMX0293120260

SHIM

81

YMX0293120270

SHIM

81

YMX0293120290

SHIM

81

YMX0293120300

SHIM

81

YMX1394200400

SHIM, 0.700 mm

90

YMX0296220190

GASKET

91

YMX1313301800

COVER

92

YMX0200062040

BOLT

93

YMX1313211900

GASKET

94

YMX0131214140

NUT

95

YMX0293214010

SPRING WASHER

96

YMX0294704030

KEY

97

YMX0297314680

BOLT

98

YMX0265141840

GASKET

99

YMX0296375020

O-RING

100

YMX0297310120

BOLT

101

YMX0265101340

GASKET

Выбрано товаров: 103
