Запчасти Komatsu PC110R-1 МОТОР ХОДА (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

226-60-15290

TRAVEL MOTOR, ASSY.

1

226-60-15310

BASE PLATE, ASSY.

\1

226-60-15370

CYLINDER BLOCK KIT

2

TIMING PLATE

3

SPACER

4

SPRING

5

SHIM

6

RING, SNAP

7

CYLINDER BLOCK

8

PIN

9

THRUST BALL

10

DISK

11

PISTON

\11

226-60-15380

KIT, SWASH PLATE

12

SWASH PLATE

13

BALL

14

PISTON

15

SPRING

\15

226-60-15390

KIT, SHAFT

16

SHAFT

\16

226-60-15410

KIT, SNAP RING

17

SNAP RING

\17

226-60-15420

KIT, BEARING

18

BEARING

19

BEARING

\19

226-60-15430

KIT, BRAKE

20

SPRING

21

SPRING

22

PISTON

23

PIN

24

SPACER

25

DISK

26

BRAKE DISK

\26

226-60-15440

GASKET KIT

27

O-RING

28

RING, WEAR

29

O-RING

30

O-RING

31

RING, WEAR

32

O-RING

33

O-RING

34

O-RING

35

O-RING

36

O-RING

37

O-RING

38

O-RING

39

O-RING

40

SCREW

41

HUB
