Запчасти Komatsu PC1100SP-6 ЛЕВ. КРЫШКА(ЗАДН. ) (TROPICAL WEATHER СПЕЦ-Я.) ЧАСТИ КОРПУСА

1

21N-54-32830

FRAME

2

20Y-54-28170

BRACKET

3

01010-81230

BOLT

4

01643-31232

WASHER

5

205-54-51970

DOVE TAIL

6

01010-80616

BOLT

7

01643-30623

WASHER

8

209-54-63260

BRACKET

9

01010-81230

BOLT

10

01643-31232

WASHER

11

21N-54-32840

COVER

12

198-54-41982

LOCK ASS'Y (WELDED)

13

20Y-54-28161

HINGE (WELDED)

14

21N-54-32860

SHEET

15

21N-54-31390

SHEET

16

21N-54-31760

SHEET

17

205-54-53550

DOVE TAIL

18

01010-80616

BOLT

19

01643-30623

WASHER

20

205-54-64140

BAR

21

04050-13018

PIN

22

20B-54-12210

SPRING

23

01210-40408

SCREW

24

01641-20405

WASHER

25

01010-81230

BOLT

26

01643-31232

WASHER

27

21N-54-32850

COVER

28

20Y-54-28161

HINGE (WELDED)

29

21N-54-32880

SHEET

30

21N-54-31760

SHEET

31

205-54-64140

BAR

32

04050-13018

PIN

33

20B-54-12210

SPRING

34

01210-40408

SCREW

35

01641-20405

WASHER

36

01010-81230

BOLT

37

01643-31232

WASHER

38

01010-81230

BOLT

39

01643-31232

WASHER
