Запчасти Komatsu PC1100SE-6 ОСНОВН. НАСОС (/) (N. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
708-2L-00532
PUMP ASS'Y
|1
708-2L-00531
PUMP ASS'Y
|1
708-25-09281
SERVO VALVE ASS'Y,REAR
|1
708-25-09280
SERVO VALVE ASS'Y,REAR
|1
708-25-09681
VALVE ASS'Y,CO + NC
|1
708-25-09680
VALVE ASS'Y,CO + NC
|1
708-23-00441
BODY ASS'Y
1
BODY
2
EXPANDER
3
708-25-17460
PLUG
4
708-25-17430
SCREW
5
07000-B2010
O-RING
|5
07000-02010
O-RING
6
708-25-17131
COVER
7
01580-10806
NUT
8
708-25-17141
SPOOL
9
708-25-17150
SLEEVE
10
708-25-17160
PISTON
11
708-25-17170
COVER
12
07000-B2014
O-RING
|12
07000-02014
O-RING
13
708-25-17180
SEAT
14
708-25-17690
SPRING
15
708-25-17220
PISTON
16
708-25-17370
SEAT
17
708-25-17250
SPRING
18
708-25-17470
SEAT
19
708-23-17290
COVER
20
07000-B3028
O-RING
|20
07000-03028
O-RING
21
708-25-17380
PLUG
22
708-25-15340
SCREW
23
07000-B2021
O-RING
|23
07000-02021
O-RING
24
708-23-17240
COVER
25
708-25-17480
PISTON
26
706-75-40310
BOLT
27
01602-20619
WASHER
28
708-25-15320
BOLT
29
01602-20619
WASHER
30
01580-10806
NUT
31
07000-B2012
O-RING
|31
07000-12012
O-RING
32
07001-02012
RING,BACK-UP
33
708-25-17451
SLEEVE
34
07000-B2012
O-RING
|34
07000-02012
O-RING
35
708-25-15320
BOLT
36
01602-20619
WASHER
37
07000-B2021
O-RING
|37
07000-12021
O-RING
38
07001-02021
RING,BACK-UP
Выбрано товаров: 52
