Запчасти Komatsu PC1100SE-6 КРЕПЛЕНИЕ ДВИГАТЕЛЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

21N-01-31150

BRACKET

2

01010-81890

BOLT

3

19M-09-12870

WASHER

4

21N-01-11170

BRACKET

5

01010-82070

BOLT

6

21T-01-11130

WASHER

7

01010-82060

BOLT

8

01643-32060

WASHER

9

04020-01842

PIN

10

21T-01-11210

COLLAR

11

21N-01-11120

CUSHION

12

21T-01-11220

COLLAR

13

21N-01-11130

STOPPER

14

21N-01-11141

STOPPER

15

21N-01-00010

SHIM KIT

|15

21N-01-11220

SHIM¤ 0.5MM

|15

21N-01-11210

SHIM¤ 1.0MM

16

21N-01-11190

PLATE

17

209-01-51210

SPACER

18

01010-81645

BOLT

19

01643-31645

WASHER

20

21N-01-11150

WASHER

21

21T-01-11190

WASHER

22

208-01-11181

BOLT

23

01643-32460

WASHER

24

21N-01-31140

PLATE

25

21T-01-11210

COLLAR

26

21N-01-11120

CUSHION

27

21T-01-11220

COLLAR

28

21N-01-11130

STOPPER

29

21N-01-11141

STOPPER

30

21N-01-00010

SHIM KIT

|30

SHIM¤ 0.5MM

|30

SHIM¤ 1.0MM

31

21N-01-11190

PLATE

32

209-01-51210

SPACER

33

01010-81645

BOLT

34

01643-31645

WASHER

35

208-01-11181

BOLT

36

01643-32460

WASHER

37

21N-01-31140

PLATE
