Запчасти Komatsu PC1100LC-6 ОСНОВН. КЛАПАН (NO. КЛАПАН И СОЕДИНИТ. ЧАСТИ) ГИДРАВЛИКА

1

709-15-93402

CONTROL VALVE

1

709-15-93401

CONTROL VALVE,(SEE FIG. Y1665-01A0)

1

709-15-93400

CONTROL VALVE,(SEE FIG. Y1665-01A0)

2

21N-62-31201

FILTER ASS'Y,(SEE FIG. Y1860-11A0)

3

21N-62-31260

BLOCK

4

21T-09-11510

O-RING

5

01011-81410

BOLT

6

01643-31445

WASHER

7

21T-09-11510

O-RING

8

07235-10315

ELBOW

9

07002-12034

O-RING

10

07235-10315

ELBOW

11

07002-12034

O-RING

12

209-62-27580

TEE

13

120-Y46-7911

NIPPLE

14

07002-12034

O-RING

15

07235-10315

ELBOW

16

07002-12034

O-RING

17

209-62-27580

TEE

18

14F-62-81420

NIPPLE

19

07002-12034

O-RING

20

07235-10315

ELBOW

21

07002-12034

O-RING

22

209-62-27580

TEE

23

07002-12034

O-RING

24

07235-10315

ELBOW

25

07002-12034

O-RING

26

209-62-78940

ELBOW

27

07002-12034

O-RING

28

07042-30108

PLUG

29

21T-62-29960

TEE

30

07002-11423

O-RING

31

209-62-67470

ELBOW

32

07042-30108

PLUG

33

07002-11423

O-RING

34

21N-62-33190

FLANGE

35

21T-09-11510

O-RING

36

01252-71460

BOLT

37

01643-31445

WASHER

38

21N-62-33270

BRACKET

39

01011-81490

BOLT

40

01643-31445

WASHER
