Запчасти Komatsu PC1100-6 ГИДР. БАК. (БАК) (С ЗАЩИТА ОТ ВАНДАЛИЗМА) ГИДРАВЛИКА

1

209-60-51120

STRAINER

2

21N-09-11140

O-RING

3

201-60-12190

CAP ASS'Y

4

201-60-12171

FILLER NECK

5

20Y-60-21340

GASKET

6

01252-70516

BOLT

7

01601-20513

WASHER

8

205-60-51480

SCREEN

9

209-60-51161

COVER

10

07000-15230

O-RING

11

209-60-51140

COVER

|11

09455-02013

HINGE

12

209-60-51150

BRACKET

13

205-60-71220

LOCK ASS'Y

14

01010-81240

BOLT

15

01643-31232

WASHER

16

12R-60-11230

SPRING

17

21N-60-31120

SUPPORT

18

21N-60-31111

TANK

19

203-60-31100

ELBOW ASS'Y

20

21T-60-71160

TUBE

21

198-60-55510

BREATHER

|21

424-U40-1120

BREATHER,(SEE FIG. Y1868-01A0)

22

566-03-11240

TUBE

23

07280-01110

CLAMP

24

21N-60-32950

STRAINER

25

21N-60-31230

SPACER

26

102-10-43260

SPRING

27

150-67-12331

WASHER

28

01010-80825

BOLT

29

01643-30823

WASHER

30

21N-60-31221

COVER

31

01010-81230

BOLT

32

01643-31232

WASHER

33

07000-12095

O-RING

34

07044-12412

PLUG

35

07002-12434

O-RING
