Запчасти Komatsu PC1100-6 НИЖН. ГИДРОЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

21N-63-X3160

CYLINDER GROUP,BOTTOM DUMP¤ L.H.

G-1

21N-63-X3170

CYLINDER GROUP,BOTTOM DUMP¤ R.H.

|1

21N-63-03160

CYLINDER ASS'Y,BOTTOM DUMP

1

21N-63-96340

CYLINDER

2

207-63-76170

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07043-00108

PLUG,GREASE

5

707-27-14830

HEAD,CYLINDER

6

707-51-90030

PACKING,ROD (KIT)

7

707-51-90630

RING,BUFFER (KIT)

8

707-52-90650

BUSHING

9

195-63-94170

SEAL,DUST (KIT)

10

07179-13104

RING,SNAP

11

707-71-34610

COLLAR

12

07000-15130

O-RING (KIT)

13

707-35-91420

RING,BACK-UP (KIT)

14

01010-81875

BOLT

15

707-41-11840

WASHER

16

21N-63-96320

ROD,PISTON

17

707-76-90040

BUSHING

18

07145-00090

SEAL,DUST (KIT)

19

07043-00108

PLUG,GREASE

20

707-36-14370

PISTON

21

07000-15080

O-RING (KIT)

22

707-35-90940

RING,BACK-UP (KIT)

23

707-44-14910

RING

24

707-39-14820

RING,WEAR (KIT)

25

707-44-14180

RING,PISTON (KIT)

26

707-71-60950

PLUNGER

27

01310-01216

SCREW

28

21N-63-96370

TUBE,L.H.

|28

21N-63-96470

TUBE,R.H.

29

21N-62-13750

TUBE,L.H.

|29

21N-62-13740

TUBE,R.H.

30

07000-13035

O-RING (KIT)

31

01435-01055

BOLT

32

21N-62-13640

BRACKET

33

209-62-53660

BAND

34

01010-81035

BOLT

35

01643-31032

WASHER

36

07282-03411

CLAMP

37

01010-81020

BOLT

38

01643-31032

WASHER

39

07378-11000

HEAD

40

07371-31049

FLANGE

41

07000-13032

O-RING

42

07372-21035

BOLT

43

01643-51032

WASHER

K

707-98-56210

SERVICE KIT
