Запчасти Komatsu PC1100-6 ЦИЛИНДР КОВША (FR LADER) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

21N-63-X3140

CYLINDER GROUP,L.H.

G-1

21N-63-X3150

CYLINDER GROUP,R.H.

|$3

21N-63-03140

CYLINDER ASS'Y

1

21N-63-76340

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-27-20630

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

6

707-51-14630

RING,BUFFER (KIT)

7

707-52-91150

BUSHING

8

198-63-93170

SEAL,DUST (KIT)

9

07179-14160

RING

10

07000-15195

O-RING (KIT)

11

07001-05195

RING,BACK-UP (KIT)

12

01011-82705

BOLT

13

01643-32780

WASHER

14

21N-63-76320

ROD,PISTON

15

707-46-13010

BUSHING

16

07043-00108

PLUG

17

707-36-20300

PISTON

18

07000-12115

O-RING (KIT)

19

707-35-52860

RING,BACK-UP (KIT)

20

707-44-20910

RING

21

707-39-20820

RING,WEAR (KIT)

22

707-44-20180

RING,PISTON (KIT)

23

707-40-20870

SPACER

24

01252-61460

BOLT

25

21N-63-76370

TUBE,L.H.

25

21N-63-76470

TUBE,R.H.

26

21N-62-13420

TUBE,L.H.

26

21N-62-13430

TUBE,R.H.

27

07000-13038

O-RING (KIT)

28

01010-81245

BOLT

29

01643-31232

WASHER

30

07000-13048

O-RING (KIT)

31

01010-81450

BOLT

32

01643-31445

WASHER

33

21N-62-13461

BRACKET

34

21N-72-12190

BRACKET

35

01010-81240

BOLT

36

01643-31232

WASHER

37

07283-24346

CLIP

38

07283-23442

CLIP

39

01599-01011

NUT

40

01643-31032

WASHER

41

07000-13038

O-RING

42

07378-11210

HEAD

43

07371-51260

FLANGE

44

01010-81245

BOLT

45

01643-31232

WASHER

46

07000-13048

O-RING

47

07378-11410

HEAD

48

07371-51470

FLANGE

49

01010-81455

BOLT

50

01643-31445

WASHER

K

707-98-77210

SERVICE KIT
