Запчасти Komatsu PC110-8M0 ЦИЛИНДР КОВША T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

-

707-E1-01700

CYLINDER ASSEMBLY

1

707-13-90340

CYLINDER

2

707-58-60A20

ROD, PISTON

3

707-76-65210

BUSHING

4

07145-00065

SEAL, DUST,(Kit:K04)

5

07020-00675

FITTING, GREASE

6

707-76-65220

BUSHING

7

707-77-65110

SEAL, DUST,(Kit:K04)

8

07020-00675

FITTING, GREASE

9

707-27-90650

HEAD, CYLINDER

10

707-56-60740

SEAL, DUST,(Kit:K04)

11

07179-12074

RING, SNAP

12

707-52-90361

BUSHING

13

707-51-60860

PACKING, ROD,(Kit:K04)

14

707-51-60650

RING, BUFFER,(Kit:K04)

15

707-35-30810

RING, BACK-UP,(Kit:K04)

16

07000-B5080

O-RING,(Kit:K04)

17

707-75-60110

RING, SNAP

18

01010-81465

BOLT

19

705-17-04980

WASHER

20

707-36-90170

PISTON

21

707-44-90150

RING, PISTON,(Kit:K04)

22

707-39-90050

RING, WEAR,(Kit:K04)

23

707-44-90911

RING

24

07000-B5055

O-RING,(Kit:K04)

25

707-35-30550

RING, BACK-UP,(Kit:K04)

26

01310-01016

SCREW

27

707-86-56060

TUBE

28

02896-61015

O-RING,(Kit:K04)

29

707-86-56070

TUBE

30

02896-61015

O-RING,(Kit:K04)

31

01010-80850

BOLT

32

01643-30823

WASHER

33

07000-13025

O-RING,(Kit:K04)

34

707-88-51480

BRACKET

35

707-88-21710

BAND

36

07372-21035

BOLT

37

01643-51032

WASHER

38

01010-81025

BOLT

39

01643-31032

WASHER
