Запчасти Komatsu PC110-8M0 ЦИЛИНДР СТРЕЛЫ(ЛЕВ.) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

-

707-E1-01670

CYLINDER ASSEMBLY

1

707-13-95150

CYLINDER

2

707-58-65A20

ROD, PISTON

3

21K-70-71320

BUSHING

4

07145-00070

SEAL, DUST,(Kit:K02)

5

07020-00675

FITTING, GREASE

6

21K-70-71320

BUSHING

7

07145-00070

SEAL, DUST,(Kit:K02)

8

707-27-95650

HEAD, CYLINDER

9

707-56-65740

SEAL, DUST,(Kit:K02)

10

07179-12079

RING, SNAP

11

707-51-65860

PACKING, ROD,(Kit:K02)

12

707-51-65650

RING, BUFFER,(Kit:K02)

13

07000-B5085

O-RING,(Kit:K02)

14

707-35-30860

RING, BACK-UP,(Kit:K02)

15

707-52-90421

BUSHING

16

707-75-65110

RING, SNAP

17

01010-81465

BOLT

18

705-17-04980

WASHER

19

707-36-95040

PISTON

20

707-44-95150

RING, PISTON,(Kit:K02)

21

707-39-95030

RING, WEAR,(Kit:K02)

22

707-34-55030

O-RING,(Kit:K02)

23

707-35-30580

RING, BACK-UP,(Kit:K02)

24

707-44-95911

RING

25

01310-01016

SCREW

26

707-86-56030

TUBE

27

02896-61012

O-RING,(Kit:K02)

28

707-86-55580

TUBE

29

02896-61015

O-RING,(Kit:K02)

30

01010-80850

BOLT

31

01643-30823

WASHER

32

07000-13025

O-RING,(Kit:K02)

33

707-88-25070

BRACKET

34

707-88-21670

BAND

35

07372-21035

BOLT

36

01643-51032

WASHER

37

01010-81030

BOLT

38

01643-31032

WASHER
