МОТОР ХОДА (REDUCER)

Запчасти Komatsu PC110-8M0 МОТОР ХОДА (REDUCER) [ХОД СИСТЕМА И ITS КОМПОНЕНТЫ]

Схема запчастей Komatsu PC110-8M0 - МОТОР ХОДА (REDUCER) [ХОД СИСТЕМА И ITS КОМПОНЕНТЫ]
24
22
1
29
24
29
23
2
10
33
32
34
7
17
8
16
6
15
36
4
13
3
14
35
30
31
11
27
5
11
12
28
9
12
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

TZ609D1000-01

REDUCER

|$2

TZ600D1103-01

Carrier (1) Assembly

3

CARRIER (1)

5

Planetary Gear (1)

6

Carrier pin (1)

11

Thrust Washer (1)

16

Parallel Pin (1)

27

Needle Roller Bearing with Retainer

|$9

TZ600D1107-011

Carrier (2) Assembly

7

Carrier (2)

9

Planetary Gear (2)

10

Carrier pin (2)

12

Thrust Washer (2)

17

Parallel Pin (2)

28

Needle Roller Bearing with Retainer

|$16

TZ209-234-42BH

Floating Seal Kit

29

Floating Seal

1

TZ607D1001-00

HUB

2

TZ600D1002-00

SPINDLE

4

TZ600D1004-02

SUN GEAR(1)

8

TZ600D1008-00

SUN GEAR(2)

13

TZ800D1013-00

THRUST PLATE

14

TZ600D1014-01

COVER

15

TZ600D1015-01

CUPLING

22

TZ600D1022-00

LOCK WASHER

23

TZ600D1023-00

SHIM

24

TZ600D1024-01

RADIAL THRUST BEARING

30

TZ610B2021-00

PLUG

31

07000-12018

O-RING

32

TZARP568261-70

O-RING

33

07000-11007

O-RING

34

TZ263B2077-01

PARALLEL PIN

35

01252-31035

HEX SOCKET BOLT

36

04065-02210

C TYPE STOP RING FOR HOLE
