Запчасти Komatsu PC110-8M0 МЕХАНИЗМ ПОВОРОТА И МОТОР (КОРПУС) N [ПОВОРОТН. КРУГ И ITS КОМПОНЕНТЫ]

-

203-26-80500

SWING MACHINERY ASSEMBLY

-

203-26-85000

SWING MACHINERY ASSEMBLY

1

203-26-81111

CASE

2

22B-26-21130

GEAR, RING

3

203-26-61120

CARRIER

4

203-26-61130

CARRIER

5

203-26-61220

SHAFT

6

203-26-61150

GEAR

7

203-26-61160

GEAR

8

203-26-61170

GEAR

9

203-26-61180

GEAR

10

201-26-62240

SHAFT

11

203-26-61250

SHAFT

12

201-26-62270

BEARING

13

203-26-61270

BEARING

14

20S-26-71160

WASHER

15

09233-12920

WASHER, THRUST

16

20S-26-71250

PIN, SPRING

17

20S-26-71190

RING, SNAP

18

04064-05520

RING, SNAP

19

203-26-61280

SPACER

20

203-26-61391

SPACER

21

203-26-61310

COLLAR

22

201-26-62330

BEARING

23

203-26-61320

BEARING

24

203-26-61340

COLLAR

25

07000-12080

O-RING

26

07012-00145

SEAL, OIL

27

203-26-61360

O-RING

28

203-26-13111

ELBOW

29

07002-12434

O-RING

30

07040-11612

PLUG

31

07002-11623

O-RING

32

07049-01620

PLUG

33

04020-01638

PIN, DOWEL

34

07049-02025

PLUG
