Запчасти Komatsu PC10MR-1-B УПРАВЛЯЮЩ. КЛАПАН (9 СЕКЦ.) (/) (ВНУТР. ЧАСТИ) (ФИКС. GAUGE)GE)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22J-60-12301

VALVE ASS'Y

1

NA401100004010

O-RING

|2

NA371421329501

VALVE ASS'Y,SERVICE AND SPEED

2

BLOCK,ZT

|3

NA371421267701

SPOOL ASS'Y,P.T.O.

3

SPOOL,P.T.O.

4

NA401101010000

O-RING

5

NA440211010000

RING,BACK UP

6

NA371416994701

PLATE

7

NA371416994801

RETAINER

8

NA257417185601

SPRING

9

NA371420510501

BOLT

10

NA571417235201

SPACER

11

NA401101010000

O-RING

12

NA440211010000

RING,BACK UP

13

NA371416994701

PLATE

14

NA031110501064

SCREW

15

NA332090701014

VALVE

16

NA257417053001

SPRING

17

NA401100011010

O-RING

18

NA371416994501

SEAT

19

NA371416994601

COVER

20

NA002010504551

BOLT

21

NA355416618801

PLUG,PF1/4

|22

NA371421329601

VALVE ASS'Y,SWING

22

BLOCK,YA

|23

NA371421324201

SPOOL ASS'Y,SWING

23

SPOOL,SWING

24

NA401101010000

O-RING

25

NA440211010000

RING,BACK UP

26

NA371416994701

PLATE

27

NA371416994801

RETAINER

28

NA257417185601

SPRING

29

NA371420510501

BOLT

30

NA401101010000

O-RING

31

NA440211010000

RING,BACK UP

32

NA371416994701

PLATE

33

NA031110501064

SCREW

34

NA332090701014

VALVE

35

NA257417053001

SPRING

36

NA401100011010

O-RING

37

NA371416994501

SEAT

38

NA371416994601

COVER

39

NA002010504551

BOLT

40

NA401100014010

O-RING

41

NA251416995201

PLUG

42

NA3744202425A9

VALVE ASS'Y,ANTI-CABITATION

43

NA403100012710

O-RING

44

NA401100010010

O-RING
