Запчасти Komatsu PC100N-6 ОСНОВН. КЛАПАН (-АКТУАТОР) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-37-13101

CONTROL VALVE

|1

723-37-13100

CONTROL VALVE

|1

723-36-40100

VALVE ASS'Y

1

PISTON SUB ASS'Y

2

SLEEVE

3

SPRING

4

700-80-61260

O-RING

5

700-80-61430

RING

6

07002-13034

O-RING

|7

723-36-40400

VALVE ASS'Y

7

PISTON SUB ASS'Y

8

SLEEVE

9

SPRING

10

700-80-61260

O-RING

11

700-80-61430

RING

12

07002-13034

O-RING

|13

723-36-41100

VALVE ASS'Y

13

PISTON SUB ASS'Y

14

SLEEVE

15

SPRING

16

700-80-61260

O-RING

17

700-80-61430

RING

18

07002-13034

O-RING

|19

723-36-42101

VALVE ASS'Y

19

PISTON SUB ASS'Y

20

SLEEVE

21

SPRING

22

700-80-61260

O-RING

23

700-80-61430

RING

24

07002-13034

O-RING

|25

723-36-42401

VALVE ASS'Y

25

PISTON SUB ASS'Y

26

SLEEVE

27

SPRING

28

700-80-61260

O-RING

29

700-80-61430

RING

30

07002-13034

O-RING

|31

723-36-40301

VALVE ASS'Y

31

PISTON

32

SEAL

33

SLEEVE

34

SPRING

35

700-80-61260

O-RING

36

700-80-61430

RING

37

07002-13034

O-RING
