Запчасти Komatsu PC100N-6 ХОД MTOR (/) (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

202-60-73102

TRAVEL MOTOR ASS'Y

|1

TZ265B200000EP

MOTOR,HYDRAULIC

|1

TZ266B2100-02

FLANGE ASS'Y

1

TZ266B2101-02

FLANGE KIT,REAR

2

TZGM1-8

PLUG

3

TZGDL1-16-S

PLUG

4

TZ263B2079-00

ORIFICE

5

TZ121F2070-00

ORIFICE

6

TZ850A0006-00

PLATE¤ NAME

7

TZ869A2052-00

RETAINER

8

TZ860A2056-00

SPRING

9

TZ860A2051-00

PLUG

10

TZJB2401-P26-9

O-RING (K1)

11

TZ860A2054-01

VALVE

12

TZ860A2055-01

SPRING

13

TZ860A2053-02

PLUG

14

07000-12016

O-RING (K1)

15

TZ200B2073-00

VALVE

16

TZ300B2039-00

STOPPER

17

TZ300B2043-01

SPRING

18

TZ300B2042-00

RING

19

TZ512B2021-00

PLUG

20

07000-12011

O-RING (K1)

21

04260-00952

BALL

22

TZ263B2002-01

SHAFT

23

TZ263B2048-00

BEARING,BALL

24

TZ15Z-22-42-10

SEAL,OIL (K1)

25

TZ263B2014-00

COLLAR

26

TZ263B2004-04

BLOCK,CYLINDER

27

TZ263B2007-01

PLATE,RETAINER

28

TZ263B2105-00

PISTON KIT (9 PIS)

29

TZ263B200301-E

PLATE,SWASH

30

TZ263B2008-00

BOWL,THRUST

31

TZ263B2070-00

PISTON

32

TZ263B2090-00

SPRING

33

TZ263B2076-02

PIVOT

34

TZ263B2077-01

PIN

35

TZ263B2011-03

WASHER

36

TZ263B2098-00

PIN

37

TZ263B2093-01

SPRING

38

TZ880A2010-00

WASHER

39

TZTH-R-42

RING,SNAP

40

TZ263B2009-01

PLATE,TIMING

41

TZ263B2049-00

BEARING,BALL

42

TZJB1354-10-25

PIN

43

TZ263B2074-00

PLATE

44

TZ800A2015-00

PLATE

45

TZ800A2016-00

PLATE

46

TZ266B2012-00

PISTON

47

TZ800A2013-00

SPRING

48

TZ266B2035-00

O-RING

49

TZ266B2039-00

O-RING

50

TZ100A2021-00

PLUG

51

07002-02034

O-RING

52

01252-31030

BOLT

53

TZJB1354-4-10

PIN

54

07000-12018

O-RING
