Запчасти Komatsu PC100N-6 ОСНОВН. КОНСТРУКЦИЯ (P.P.C. РАБОЧАЯ ЛИНИЯ)(№9-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

702-16-01180

PILOT VALVE,(SEE FIG.Y0670-11A0)

2

07230-20210

UNION

3

07002-01423

O-RING

4

07236-10210

ELBOW

5

07002-01423

O-RING

6

201-62-73610

HOSE¤ 1745MM,YELLOW

|6

201-62-73380

HOSE¤ 1720MM,YELLOW

7

201-62-73610

HOSE¤ 1745MM,BLUE

|7

201-62-73380

HOSE¤ 1720MM,BLUE

8

201-62-73620

HOSE¤ 1805MM,RED

|8

201-62-72940

HOSE¤ 1780MM,RED

9

201-62-73620

HOSE¤ 1805MM

|9

201-62-72940

HOSE¤ 1780MM

10

201-62-72660

HOSE¤ 1330MM,BLUE

11

203-62-57632

HOSE¤ 1240MM,RED

12

07000-02018

O-RING

13

07000-02015

O-RING

14

702-16-53240

PLUG

15

20Y-62-16170

BOLT

16

01010-80820

BOLT

17

01643-30823

WASHER

18

702-16-01180

PILOT VALVE,(SEE FIG.Y0670-11A0)

19

07230-20210

UNION

20

07002-01423

O-RING

21

07236-10210

ELBOW

22

07002-01423

O-RING

23

201-62-73630

HOSE¤ 1845MM,BROWN

|23

201-62-73410

HOSE¤ 1820MM,BROWN

24

20U-62-23930

HOSE¤ 2030MM,BLACK

|24

203-62-62830

HOSE¤ 2000MM,BLACK

25

203-62-62670

HOSE¤ 1200MM,BLUE

26

201-62-73620

HOSE¤ 1805MM,GREEN

|26

201-62-72940

HOSE¤ 1780MM,GREEN

27

203-62-57642

HOSE¤ 1470MM,RED

28

20X-62-47420

HOSE¤ 1925MM,WHITE

|28

203-62-63350

HOSE¤ 1900MM,WHITE

29

07000-02018

O-RING

30

07000-02015

O-RING

31

702-16-53240

PLUG

32

20Y-62-16170

BOLT

33

08034-00834

BAND

34

01010-80820

BOLT

35

01643-30823

WASHER

36

20Y-62-22170

CLAMP

37

203-62-63290

CLAMP

38

01010-81016

BOLT

39

01643-31032

WASHER
