Запчасти Komatsu PC100L-5 ГИДРАВЛ УПРАВЛЯЮЩ. КЛАПАН ЛЕВ.(/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
№
Артикул
Название
Примечание
Количество
|1
700-86-45001
VALVE ASS'Y,L.H.
|1
700-86-35003
VALVE ASS'Y,L.H.
|1
700-86-35002
VALVE ASS'Y,L.H.
1
BODY,VALVE
|1
BODY,VALVE
2
BLOCK,VALVE
|2
BLOCK,VALVE
3
BLOCK,VALVE
|3
BLOCK,VALVE
4
BLOCK,VALVE
5
07000-03038
O-RING
6
07000-13050
O-RING
7
700-84-11330
BRACKET
8
01010-51020
BOLT
9
709-74-91860
PLUG
10
07002-12434
O-RING
11
700-42-31460
VALVE
12
700-42-31470
SPRING
13
700-84-11320
PLUG
14
07002-13034
O-RING
15
07040-13316
PLUG
16
07002-13334
O-RING
17
709-74-91510
PLUG
|17
700-84-13960
PLUG
18
07000-11009
O-RING
|18
700-22-11410
O-RING
19
07001-01009
RING,BACK-UP
|19
700-80-64220
RING,BACK-UP
20
709-25-11390
O-RING
|20
07002-03034
O-RING
21
SPOOL,SERVICE
22
SPOOL,BOOM HIGH
23
SPOOL,SWING
24
SPOOL,SWING PRIORITY
25
700-84-11650
SPRING
26
700-84-13711
RETAINER
27
700-84-11641
COLLAR
28
01252-30830
BOLT
29
01643-30823
WASHER
30
700-84-11390
COVER
31
700-84-13891
PLATE
32
700-84-13910
SEAL
33
01252-30612
BOLT
34
700-84-15720
SPRING
35
700-84-15740
SPRING
36
700-84-13790
JOINT
37
07002-11223
O-RING
38
700-84-13781
RETAINER
39
700-84-13490
PLATE
40
700-84-12510
CASE
41
700-84-11240
O-RING
42
01252-30616
BOLT
43
01252-30625
BOLT
44
07040-11409
PLUG
45
07002-01423
O-RING
46
700-84-13570
SPRING
47
700-84-13870
PLUG
48
07002-02434
O-RING
49
700-84-13510
NIPPLE
50
07000-02015
O-RING
51
07002-02434
O-RING
52
709-80-52800
VALVE ASS'Y,RELIEF
53
709-20-81201
VALVE ASS'Y,SUCTION
|53
700-81-82001
VALVE ASS'Y,SUCTION
|53
700-81-81000
VALVE ASS'Y,SUCTION
Выбрано товаров: 65
